Infinity-edge stainless steel pool: pure design, maximum effect
Introducing the sleek, stainless steel, infinity-edge pool with a full-perimeter overflow. It is a testament to precision craftsmanship, quality materials, and timeless design. With impressive dimensions of 20 x 2.5 x 1.35 metres, this outdoor pool is the ideal solution for clients looking for the ultimate swimming experience, as well as a striking architectural feature for their garden or patio.
The design and technology of the overflow system
The infinity edge creates the effect of an infinite water surface that gracefully disappears behind the horizon. This optical illusion connects the pool to the surrounding landscape, providing a unique aesthetic experience. The pool is constructed in a concrete sump with a stainless steel body and an overflow around the entire perimeter, covered by a 245 mm wide grey PVC grid. The overflow technology also ensures perfect circulation and crystal-clear water without surface tension.
For maximum safety during movement, the bottom of the pool and the entrance steps have been fitted with circular anti-slip siping. The brushed surface of the pool walls not only looks great, but is also pleasant to the touch. The assembly was carried out on site with the utmost care taken over all welds to ensure longevity and a perfect appearance.
Lighting and entrance
The pool is fitted with nine 150 mm diameter white LED lights from Wibre, which create a captivating atmosphere for evening swimming. The entrance to the water features two recessed ladders that are integrated into the pool walls without disturbing the overall aesthetics.
The equipment includes two 10 x 2.5 metre solar-powered PVC slat covers. These are integrated into the bottom of the pool, allowing them to remain hidden when not in use. These solar slats help to heat the water while minimising evaporation, thereby reducing running costs.
Technology and water treatment
The stainless steel pool is equipped with two Behncke FEX 3/800 laminate filters, automatic 5-way valves, two Behncke ECO VS circulating pumps with a frequency converter, and an advanced Aseko Aqua HOME VS automatic chemigation system. Water is stored in a 5.5 m³ PP tank, and the system is fitted with intelligent level monitoring, underflow and pressure control.
Would you like to discuss this project or a similar one? Send us a no-obligation enquiry and we will develop a bespoke project for you.
