The TAO TRUST sauna and cooling pool with a mobile terrace

The TAO TRUST sauna and cooling pool with a mobile terrace

For our client from Moravia, we created a sauna and cooling pool design that combines perfect aesthetics with thoughtful functionality. The indoor premium TAO TRUST Finnish sauna and the outdoor IMAGINOX stainless steel cooling pool, protected by an elegant mobile cover, are part of a beautiful private wellness area.

Finnish sauna TAO TRUST – perfect comfort and design

The TAO TRUST sauna is an indoor Finnish sandwich cabin with dimensions of 260 × 230 × 256 cm. The front and partly side walls are glazed and made of tempered clear glass, which creates a feeling of open space and visually connects the sauna with the surroundings. The entrance door is 70 cm wide, made of 8 mm thick single-panel tempered clear glass and has a frame and a Trust design handle.

The interior is lined with large hemlock panels, which are distinguished by their fine texture and durability. The TRUST benches are two-tiered and arranged in an L-shape. They are made of Abachi softwood with Conti straight backrests. The upper bench is 70 cm wide and the lower bench is 60 cm wide. There is no step stool or headrest.

Lighting and entrance

The interior lining is made of large Hemlock panels, which are distinguished by their fine texture and durability. TRUST benches are two-tiered, arranged in an “L” shape, in Abachi softwood with Conti straight backrests. The upper bench has a width of 70 cm, the lower one 60 cm, there is no step stool or two headrests.

The sauna is heated by a 9 kW EOS Bio Invisio XL under-valve electric heater with a Sanarium system and an EOS EmoStyle H touch control panel. Premium accessories are also included: an hourglass, a thermometer, a Trust bucket with scoop, and a set of aromas. The sauna is made to measure and includes precise assembly and complete commissioning.

Stainless steel cooling pool IMAGINOX – refreshment after sauna

To achieve the ideal sauna cycle, we have installed a rectangular IMAGINOX cooling pool made of stainless steel with internal dimensions of 1.8 × 1.0 × 1.2 m. It has a non-slip, slip-resistant surface on the bottom and stairs, as well as a straight four-step staircase across the entire width.

The circulation system includes a drainage slot in the wall and a bottom nozzle for automatic filling and timed draining. The water temperature ranges from 6 to 10 °C, and the pool is equipped with a Wibre blue LED RGB spotlight for an evening ambience.

Retractable Aquafloor Cover – a practical and aesthetic solution

To protect the cooling pool and maximise space utilisation, we designed and manufactured a mobile Aquafloors cover measuring approximately 2.2 x 1.4 metres. The painted aluminium structure is reinforced to support the granite tiling and is complemented by a compact Nidaplast board. The terrace moves on rails running parallel to the pool’s shorter side, and features a manual offset with locking and thermal insulation made of cellular polycarbonate.

The movable cover protects the water surface from dirt and allows the area above the pool to be used as a walking or relaxation area. This project exemplifies how luxury materials, modern technology, and precise craftsmanship can be combined to create a harmonious whole that will endure for many years. Would you like an indicative quote for your project?
